Exclusive from TrimPleat: Now You Can do Precise Crosscutting and Pleat Trimming With Just One Unit!

Why is the TrimPleat Rotary Pleat Pack System so efficient? How does it work? First, using a proprietary blade configuration to produce fast, straight, and repeatable cuts, the TrimPleat Rotary Pleat Pack crosscutter cuts continuous pleated material into pleat packs.


Then, powerful twin rotating blades cleanly trim the pleat bundles to the final width– within .005”– to produce a finished pleat pack. Automatic pleat trimming system controls move the blades in or out to correspond with desired pleat width.


What makes the TrimPleat Rotary Pleat Pack System the best unit for pleat cross cutting and trimming? An intelligent motor drives precision ball screws to move the blades. Widths are entered manually, or selected from recipes you create and store in memory. Proprietary pleat clamp tooling–specific to your product–securely holds pleated material in place during the trimming operation. Only with the TrimPleat Rotary Pleat Pack System are flared ends and ragged cuts virtually eliminated.

Cuts are much straighter so filters fit tightly around housing–resulting in less product failure due to leakage. The TrimPleat System is an excellent solution for all Bio-med Filter Trimming and Food Processing Filter Trimming requirements. Any time product leakage is an issue, the TrimPleat System provides the optimum solution.


Additional TrimPleat Rotary Pleat Pack System Product Features: An exclusive blade motion profile feature is included on every automated pleat trimming system.

This feature provides continuous automatic adjustment of Blade width, Blade speed, and Blade feed speed simultaneously during the trimming sequence.

A graphics display allows easy setup and development of motion profiles and saving of “recipes” that include the motion profile parameters. Five presets for each parameter are included and can be easily modified and saved. These saved recipes are then quickly recalled for repeat jobs.

Contact us today to learn how we can make your filter trimming operations more accurate and efficient with the TrimPleat Rotary Pleat Pack System.
